S9 HD PVR DVB-S2 digital tv receiver dreambox

Product Description 1. SKY S9 HD USB PVR MHEG5 UK 2.Linux operating system 3.Ethernet & Cccam 4.Same function with Dm8000 5.One year warranty... *Accessories: Main board(DB-M3602-02V01)ALI48 keys IR controller, USB HDD BOX(customeroption) *Board configuration: 396MHz MIPS CPU, 128MB ddr400RAM,Memory clock 198Mhz,2MB serial Flash, single Tuner,DVB-S2 demodulator, *Power SUPPLY: Input 100v-240v 50/60Hz *Power Consumption: 30W Max/1W Standby (it`s optional by customer`s board *RS232: For Fw Upgrading. *Standard Receiver Standard: DVB-S2 Standard (ETSI EN 302 307) *Input Frequency Range: 950MHz- 2150Mhz *Input Signal Level: -25dBm- -65dBm *Demodulation: QPSK, 8PSK, 16APSK *Transport Stream: MPEG-2 ISO/IEC 13818 Transport Stream Specification *MPEG Profile Level: MPG2 SD, MPEG HD, H.264/AVC SD, H.264/AVC HD *LNB Power & Polarisation: Vertical+13.5v,Horizontal 18V,Current: MAX 500ma *MuLTI satellite receiving: 22K switcher, DISEqC1.0,DiSEqC1.1, Unicable, DiSEqC1.2,USAL *Conditional Access system: 1 Common Interface Slots:1 CA card reader Slots *A/V Output orts: YprpB,RCA with CVBS, SCART with cvbs, HDMI(HDCP) ;Left/Right analog audiooutput(RCA),Digital audil output (SPDIF with coaxial or fiber) *Aspect Ratio: Auto,16:9 Pillar box 4:3 PAN&Scan,4:3 LETTER BOX *Audio Decoding: MPEG1 laver 1,MPEG1 layer ll,MPEG1 layer lll,MPEG2.AC3. *Audio MODE: Stereo/MONO/Left/Right *DVR supporting: DVR with USB hdd, Time shifting with USB HDD *USB2.0 High SPEED HOST: 1 USB2.0 Port, USB MEDIA player to Playback the media in USB flash disk or USB HDD or USB card READER with memory card or fw UPGRADING. *File system:FAT12 FAT16,FAT32,NTFS(only support first partition) *Media Supporting: JPG,BMP,MP3,WMA *Ethermet Interface: 10/100Mbit *STORAGE temperature: 0´C to +50´C
